Owon CP07+ 1MHz - 4A current probe

Test Range 400mA - 4A
Resolution 0.1mA
Bandwidth DC 1MHz (±3dB)
Jaw Size 5mm (max)
Auto Zero at Power-on
Power Supply 9V 6F22 Battery
Operating Temperature 0℃ to 50℃
Operating Humidity 15% to 70% RH
DC Current Range DCA 400mA DCA 4A
Accuracy ±1.5%rdg ± 5-digit
Sensitivity 1mV/1mA 1mV/10mA
AC Current Range ACA 400mA ACA 4A
Accuracy ±2.0%rdg ± 5-digit
Sensitivity 1mV/1mA 1mV/10mA
Dimension (W x H x D) 215 x 36 x 58mm
Device Weight 200g
70 000 Ft + ÁFA (Br. 88 900 Ft)
